Model

UD-181LB

Printhead

Epson DX5

Number of printhead

1 Head

Maximum print width

1,800mm

Print Speed (m2/h)

Print mode

Standard output(m2/h)

RD

2 PASS 30

D

3 PASS 20

S

4 PASS 15

Q

6 PASS 10

HQ

8 PASS 7

BL

12 PASS 5

Ink

Type:

Disperse Dye

Color :

4 Color (C,M,Y,K)

Capacity:

1L per Main Tank of Each Color

Ink Supply System

Auto Ink Supply System

Media Width

Maximum 1,880mm

Media Type

(Sublimation paper)Heat Transfer Paper, Polyester,Satin,Warp Knitted,Mesh Knitted fabric,Flag banner fabric…

Auto Media Feeding System

Equipped (Max. Media Weight 25kg)

Auto Cleaning System

Anti-clogged Flash Function & Capping System

Pre-heating & Drying System

Equipped

Clamp

Equipped

Print Interface

USB 2.0

Printhead Height

2 to 6 mm Above Media Adjustable

RIP Software

Ultraprint, Maintop, Photoprint, Wasatch, Ergosoft

Input Power

AC 220V, 50Hz/60Hz

Machine Dimension / N.W

L3,080 x W990 x H1,260mm / 204KG

Package Dimension / G.W

 L3,190 x W1,100 x H845mm / 390KG
