Product Model

UD-211LC

Printhead

Epson

Number of Printhead

1Heads

Printhead Sequency

1

Maximum Print Width

2100mm

Maximum Media Width

2100mm

printing mode

Print Speed

RD

2 PASS 32 m²/hr

D

3 PASS 21 m²/hr

Standard mode(S)

4 PASS 16 m²/hr

Q

6 PASS 11 m²/hr

High quality mode（HQ）

8 PASS 8 m²/hr

BL

12 PASS 5 m²/hr

Ink Type

Eco Solvent Ink

Ink Color

4Color C\M\Y\K

Ink Supply System

Low Ink Detector,Auto or Manual Ink Supply System

Auto Cleaning System

Positive Cleaning Anti-clogged Flash Function

RIP Software

Maintop, PhotoPrint, UltraPrint

Print Interface

USB2.0

Printhead Height

2 to10mm Above Media Adjustable

Media Type

Vinyl,Flex,Polyester,Back-Iit Film,Window Film,etc Roll Media or SheetMedia

Auto Media Feeding System

Equipped(Max.Media Weight 80kg)

Pre-heating & Drying System

Equiped(Drying System Optional)Infra-red Heating System Optional

Clamp

Equipped

Input Power

AC220V 50HZ

Operation Environment

Temperature: 20°C--28°C, Humidity: 40%--60%

Machine Dimension

L3,380 x W990 x H1,260mm / 225KG

Package Dimension

L3,490 x W1,100 x H845mm / 422KG
