| MODEL |
UD-18C8AE |
| Printhead |
TOSHIBA CE4M |
| Number of printhead |
8 Heads |
| Print Speed (m2/h) |
Print Mode |
Outputs(m2/h) |
|
|
86 |
|
|
64 |
|
|
42 |
| MODEL |
UD-18C8AE |
| Max. printing width |
1,820mm |
| Max. media width |
1,950mm |
| Ink |
Type |
ECO Solvent Ink |
| Color |
4 Color (C,M,Y,K) |
| Volume |
1L Per Main Tank of Each Color |
| Ink supply system |
Auto ink supply system |
| Media Type |
Vinyl, Polyester, Flex, Back-lit Film, etc |
| Auto Media Feeding System |
Equipped (Max. Media Weight 40kg) |
| Cleaning System |
Anti-clogged Flash Function & Capping System |
| Pre-heating & Drying System |
Equipped |
| Clamp |
Equipped |
| Print Interface |
USB 3.0 |
| Printhead Height |
2 to 6mm from Media |
| RIP Software |
Maintop, Ultraprint, Photoprint, Onyx |
| Input Power |
AC 220V, 50Hz/60Hz |
| Operating Environment |
Humidity |
20-80% (Recommend 40-60%) |
| Temperature |
15-35°C (Recommend 20-32°C) |
| Printer Dimension/Weight |
L3,310 x W970 x H1,260mm / 204KG |
| Package Dimension/Weight |
L3,460 x W1,120 x H845mm / 381KG |
The Speed data varies in different computer. Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.
