MODEL

UD-3296EDU

Printhead

SPT1024GS

Maximum print width

6Heads

Print Speed (m2/h)

Print mode

Output(m2/h)

Draft

6Pass

36

Standard

8Pass

27

Quality

12Pass

18

High Quality

16Pass

13

Maximum print width

3,200mm

Media Width

3,300mm

Ink

Type

UV Ink

Color

C M Y K LC LM

Capacity

1L or 5L per Main Tank of Each Color

Ink Supply System

Low Ink Dectector, Auto or Manual Ink Supply System

Media Type

Vinyl, Window Film, Polyester, Flex, Back-lit Film, etc.

Auto Media Feeding System

Equipped (Max. Media Weight 80kg)

Auto Cleaning System

Individual Positive Pressure Cleaning ,Anti-clogged Flash Function & Capping System

Pre-heating & Drying System

Equipped

Clamp

Equipped

Printhead Height

2 to 6 mm from Media

Print Interface

USB 3.0

RIP Software

Maintop, Ultraprint, Photoprint, Wasatch, Topaz

Input Power

AC 220V, 50Hz/60Hz

Operation Environment

Humidity:

20-80%(Recommend 40-60%)

Temperature:

15-35℃(Recommend 20-32℃)

Machine Dimension / N.W

L4,766 x W1,160 x H1,350mm / 724KG

Package Dimension / G.W

L4,980 x W1,140 x H1,640mm /1064KG
