MODEL

UD-06C6AQV

Printhead

Toshiba CE4M

Number of printhead

5 Heads(C M Y K Lc Lm W V) One head two color

Maximum print width

600mm× 900mm × 129mm

Print Speed (m2/h)

Print mode

Output(m2/h)

Draft                6Pass

6

Standard             8Pass

4

Quality             12Pass

3

High Quality         16Pass

2

Ink

Type:

UV Ink

Color :

8 Color (C,M,Y,K,Lc,Lm,W,V)

Capacity:

1L per Main Tank of Each Color

Media Width

600mm× 900mm × 131mm

Media Type

PS Board, KT Board, PVC Foam Board, Acrylic, Aluminum, Glass, Etc

Auto Cleaning System

Positive Pressure Cleaning

Print Interface

USB 3.0

Printhead Height

1 to 150 mm from Media

RIP Software

Maintop, Ultraprint, Photoprint, Onyx, United Fancy

Input Power

AC220V/230V, 50Hz/60Hz

Printer Power

3000W

Temperature/Humidity

Recommended:20℃-32℃/ Recommended:40%-60%

Machine Dimension / N.W

L1880 × W1770 × H1460 / 180 KG

Package Dimension / G.W

L2080 × W1970 × H1640 / 410 KG
