MODEL

UD-3266E

Printhead

SPT1020-35PL

Maximum print width

6Heads

Print Speed (m2/h)

Print mode

Output(m2/h)

Draft

2Pass

75

Standard

3Pass

58

Quality

4Pass

44

High Quality

6Pass

29

Compensatory

8Pass

21

Maximum print width

3,200mm

Media Width

3,300mm

Ink

Type

Solvent Ink / ECO Solvent Ink

Color

6 Color (C,M,Y,K,Lc,Lm)

Capacity

1L or 5L per Main Tank of Each Color

Ink Supply System

Low Ink Dectector, Auto or Manual Ink Supply System

Media Type

Vinyl, Window Film, Polyester, Flex, Back-lit Film, etc.

Auto Media Feeding System

Equipped (Max. Media Weight 80kg)

Auto Cleaning System

Individual Positive Pressure Cleaning ,Anti-clogged Flash Function & Capping System

Pre-heating & Drying System

Equipped

Clamp

Equipped

Printhead Height

2 to 6 mm from Media

Print Interface

USB 2.0

RIP Software

Maintop, Ultraprint, Photoprint, Wasatch, Topaz

Input Power

AC 220V, 50Hz/60Hz

Machine Dimension / N.W

L4, 786 x W930 x H1,350mm / 724KG

Package Dimension / G.W

L4, 980 x W1,140 x H1,640mm / 1064KG
