MODEL

UD-3288XA

Printhead

SII Printek Inc SPT508GS

Number of printhead

8 Heads

Maximum print width

3,200mm

Print Speed (m2/h)

Print mode

Output(m2/h)

Draft                2Pass

297

Standard             3Pass

214

Quality              4Pass

148

High Quality          6Pass

99

Backlit              8Pass

74

Ink

Type:

Solvent Ink / ECO Solvent Ink

Color :

Double 4 Color (C,M,Y,K)

Capacity:

1L or 5L per Main Tank of Each Color

Ink Supply System

Low Ink Detector, Auto or Manual Ink Supply System

Media Width

Maximum 3,300mm

Media Type

Vinyl, Window Film, Polyester, Flex, Back-lit Film, etc.

Auto Media Feeding System

Equipped (Max. Media Weight 80kg)

Auto Cleaning System

Individual Positive Pressure Cleaning ,Anti-clogged Flash Function & Capping System

Pre-heating & Drying System

Equipped

Clamp

Equipped

Print Interface

USB 3.0

Printhead Height

2 to 6 mm from Media

RIP Software

Maintop, Ultraprint, Photoprint

Input Power

AC 220V, 50Hz/60Hz

Operating Environment

Humidity:

20-80% (Recommend 40-60%)

Temperature:

15-35°C(Recommend 20-32°C)

Machine Dimension / N.W

L4,845 x W1,070 x H1,585mm / 650KG

Package Dimension / G.W

L5,000 x W1,200 x H1,900mm /1037KG
